PIGEM

Product Grade Form Application Special Feature
China Clay PIGEM Powder Glazing of ceramic products such as wall and floor tiles, granito tiles and sanitaryware. Glazing of ceramic products such as wall and floor tiles, granito tiles and sanitaryware.

Physical Analysis

Description Analysis
Moisture(w/w) % (max) 2
pH 7.5
Oil absorption(ml/100 gm) 57
Suspension(% in 24 hours) good
-2 micron(w/w) % (min) 40
+300 mesh retention(w/w) % (max) 0.60
Natural gloss (Taking MgO as 100%) 89
Water absorption (ml/100 gm) 39
Brightness (ISO) 83

Chemical Analysis

Description Analysis
SiO2 47.42
Al2O3 37.02
Fe2O3 0.49
CaO+MgO 0.28
TiO2 0.36
Na2O + K2O 0.92
L.I.O 13.17
The results mentioned are determined by our standard laboratory test methods. Every precaution is taken in production to ensure that the product confirms to our published results; but as the material is a naturally occurring mineral, Ashapura China Clay Co. reserves the right to change the data, whenever it becomes necessary
