PIGLAZE

Product Grade Form Application Special Feature
China Clay PIGLAZE Powder / Lumps. Glazing and engobing for ceramic products such as wall and floor tiles, vitrified tiles and sanitaryware. Very low residue content and excellent firing white colour.

Physical Analysis

Description Analysis
Moisture(w/w) % (max) 4
pH 7.5
Suspension(% in 24 hours) 85
-2 micron(w/w) % (min) 74
+300 mesh retention(w/w) % (max) 0.30
Water of plasticity (%) 30
Green shrinkage(%) 2.41
Fired gloss (%) 90

Chemical Analysis

Description Analysis
SiO2 45.40
Al2O3 37.52
Fe2O3 0.40
CaO+MgO 0.16
TiO2 0.75
Na2O + KM2O 0.10
L.I.O 13.84
The results mentioned are determined by our standard laboratory test methods. Every precaution is taken in production to ensure that the product confirms to our published results; but as the material is a naturally occurring mineral, Ashapura China Clay Co. reserves the right to change the data, whenever it becomes necessary
